Product Summary
The PI6C185-01L is a high-speed low-noise 1-5 non-inverting buffer designed for SDRAM clock buffer applications. The PI6C185-01L is intended to be used with the PI6C10X clock generator for Intel Architecture-based Mobile systems. At power-up, all SDRAM outputs are enabled and active. The I2C Serial control may be used to individually activate/deactivate any of the 5 output drivers.
Parametrics
PI6C185-01L absolute maximum ratings: (1)Storage Temperature : –65°C to +150°C; (2)Ambient Temperature with Power Applied : –40°C to +85°C; (3)3.3V Supply Voltage to Ground Potential : –0.5V to +4.6V; (4)DC Input Voltage : –0.5V to +4.6V; (5)IDD Supply Current BUF_IN = 133.3 MHz: 200mA; (6)LPIN Pin Inductance: 7 nH.
Features
PI6C185-01L features: (1)High-speed, low-noise non-inverting 1-5 buffer; (2)Switching speed up to 140 MHz; (3)Supports up to two SODIMMs; (4)Low skew (<250ps)between any two output clocks; (5)I2C Serial Configuration interface; (6)Multiple VDD, VSS pins for noise reduction; (7)3.3V power supply voltage.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() PI6C185-01LE |
![]() Pericom |
![]() Clock Buffer Precision 1:5 Clock Driver |
![]() Data Sheet |
![]()
|
|
||||||||||
![]() |
![]() PI6C185-01LEX |
![]() Pericom |
![]() Clock Buffer Precision 1:5 Clock Driver |
![]() Data Sheet |
![]()
|
|
