Product Summary

The RK73H2ATE24R9F (FULL) is a Thick Film Resistor.

Parametrics

RK73H2ATE24R9F (FULL) absolute maximum ratings: (1)Power Rating @ 70°C: 1/8W (125W); (2)Absolute Maximum Working Voltage: 150V; (3)Absolute Maximum Overload Voltage: 200V; (4)Operating Temperature Range: -55℃ to +155℃.

Features

RK73H2ATE24R9F (FULL) features: (1)Marking: 1F, 1H, 1E no marking, black body; 1J: three-digit black marking (E-24 only) on blue protective coat; 2A ~ 3A four-digit; (2)black marking on blue protective coat; (3)Products with lead-free terminations meet EU RoHS requirements; EU RoHS regulation is not intended for Pb-glass contained in electrode, resistor element and glass.

Diagrams

RK73H2ATE24R9F (FULL) pin connection
