Product Summary

The SN74ACT374DWR is an OCTAL d-type edge-triggered FLIP-FLOP. It is particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers. To ensure the high-impedance state during power up or power down, OE should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

Parametrics

SN74ACT374DWR absolute maximum ratings: (1)Supply voltage range, VCC:–0.5 V to 7 V; (2)Input voltage range, VI:–0.5 V to VCC + 0.5 V; (3)Output voltage range, VO:–0.5 V to VCC + 0.5 V; (4)Input clamp current: ±20 mA; (5)Output clamp current: ±20 mA; (6)Continuous output current: ±50 mA; (7)Continuous current through: ±200 mA; (8)Package thermal impedance DB package: 70°C/W; (9)Storage temperature range, Tstg:–65°C to 150°C.

Features

SN74ACT374DWR features: (1)4.5-V to 5.5-V VCC Operation; (2)Inputs Accept Voltages to 5.5 V; (3)Max tpd of 10 ns at 5 V; (4)Inputs Are TTL-Voltage Compatible.

Diagrams

SN74ACT374DWR pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SN74ACT374DWR
SN74ACT374DWR

Texas Instruments

Flip Flops Tri-State Octal

Data Sheet

0-1: $0.43
1-25: $0.34
25-100: $0.29
100-250: $0.26
SN74ACT374DWRE4
SN74ACT374DWRE4

Texas Instruments

Flip Flops Octal D-Ty Edge-Trig F-F W/3-State Otpt

Data Sheet

0-1: $0.43
1-25: $0.34
25-100: $0.29
100-250: $0.26
SN74ACT374DWRG4
SN74ACT374DWRG4

Texas Instruments

Flip Flops Octal D-Type Edge- Triggered

Data Sheet

0-1: $0.43
1-25: $0.34
25-100: $0.29
100-250: $0.26
