Product Summary

The AH103AG is a high gain, high linearity 1/2-Watt amplifier. This device is comprised of two individual MMIC amplifiers internally and can be used with an external interstage match for any of the mobile infrastructure frequency bands. The dual-stage amplifier achieves up to +46 dBm IP3 performance with 28.5 dB gain. It can be used in (1)Mobile Infrastructure; (2)W-LAN / ISM / RFID; (3)MDS / MMDS Infrastructure.

Parametrics

AH103AG absolute maximum ratings: (1)Operating Case Temperature: -40 to +85 °C; (2)Storage Temperature: -55 to +125 °C; (3)DC Voltage (pin 2): +6 V; (4)DC Voltage (pin 6, 7): +11 V; (5)RF Input Power (continuous): 4 dB above Input P1dB; (6)Junction Temperature: +220°C.

Features

AH103AG features: (1)60-2700 MHz; (2)+27 dBm P1dB; (3)+46 dBm Output IP3; (4)28.5 dB Gain @ 900 MHz; (5)Excellent ACPR; (6)MTTF > 100 Years; (7)SOIC-8 Pkg w/ heat slug.

Diagrams

AH103AG pin connection
