Product Summary

The OP97E is a low power alternative to the industry-standard OP97 precision amplifier. It maintains the standards of performance set by the device while utilizing only 600 μA supply current, less than 1/6 that of an OP97E. Offset voltage is an ultralow 25 μV, and drift over temperature is below 0.6 μV/℃. External offset trimming is not required in the majority of circuits. The OP97E conforms to the OP97E pinout, with the null potentiometer connected between Pins 1 and 8 with the wiper to V+.

Parametrics

OP97E absolute maximum ratings: (1)Supply Voltage: ±20 V; (2)Input Voltage: ±20 V; (3)Differential Input Voltage: ±1 V; (4)Differential Input Current: ±10 mA; (5)Output Short-Circuit Duration: Indefinite; (6)Operating Temperature Range: –40℃ to +85℃; (7)Storage Temperature Range: –65℃ to +150℃; (8)Junction Temperature Range: –65℃ to +150℃; (9)Lead Temperature (Soldering, 60 sec): 300℃.

Features

OP97E features: (1)Low Supply Current: 600 μA Max; (2)OP97E Type Performance Offset Voltage: 20 μV Max; Offset Voltage Drift: 0.6 μV/℃ Max; (3)Very Low Bias Current 25℃: 100 pA Max; –55℃ to +125℃: 250 pA Max; (4)High Common-Mode Rejection: 114 dB Min; (5)Extended Industrial Temperature Range: –40℃ to +85℃; (6)Available In Die Form.

Diagrams

OP97E diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
OP97EJ8
OP97EJ8
Linear Technology
IC OPAMP PREC LP 8-CDIP
Data Sheet
Negotiable
OP97EPZ
OP97EPZ

IC OPAMP GP LP PREC 8DIP
Data Sheet
0-1: $4.66
1-10: $4.19
10-25: $3.82
25-100: $3.45
100-250: $3.17
250-500: $2.89
500-1000: $2.52
1000-2500: $2.48
OP97EP
OP97EP

IC OPAMP GP LP PREC 8DIP
Data Sheet
0-50: $4.34
OP97EN8
OP97EN8

IC PREC OPAMP LOW POWER 8-DIP
Data Sheet
0-1850: $2.34
OP97EN8#PBF
OP97EN8#PBF

IC PREC OPAMP LOW POWER 8-DIP
Data Sheet
Negotiable
