SN74LVCC4245APWR

SN74LVCC4245APWR, octal dual-supply bus transceiver, 6 V, 100 mA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.23~1.64 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 500 :	1.64 / Piece
500 ~ 1000 :	0.45 / Piece
1000 ~ 1500 :	0.23 / Piece

PartNumber:: SN74LVCC4245APWR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 05+

Availability:: Supply Ability: 10000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. harry's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-05

From Other Seller

Part Number:SN74LVCC4245APWR
US $0.23 - 1.64
Quantity:

piece

Product Summary

The SN74LVCC4245APWR is an octal dual-supply bus transceiver. This is dedicated to accepting a 5-V supply level, and the configurable B port, which is designed to track VCCB, accepts voltages from 3 V to 5 V. This allows for translation from a 3.3-V to a 5-V environment and vice versa. The SN74LVCC4245A is designed for asynchronous communication between data buses. The device transmits data from the A bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control (DIR) input. The output-enable (OE) input can be used to disable the device so the buses effectively are isolated. The control circuitry (DIR, OE) is powered by VCCA.

Parametrics

SN74LVCC4245APWR absolute maximum ratings: (1)VCCA Supply voltage range: –0.5 to 6 V; (2)Input voltage range (2)I/O ports (B port): –0.5 VCCB + 0.5 V; (3)VO Output voltage range (2)V B port: –0.5 VCCB + 0.5 V; (4)IIK Input clamp current VI < 0: –50 mA; (5)IOK Output clamp current VO < 0: –50 mA; (6)IO Continuous output current: ±50 mA; (7)Continuous current through VCCA, VCCB, or GND: ±100 mA; (8)θJA Package thermal impedance PW package: 88°C/W; (9)Tstg Storage temperature range: –65 to 150 °C.

Features

SN74LVCC4245APWR features: (1)Bidirectional Voltage Translator; (2)4.5 V to 5.5 V on A Port and 2.7 V to 5.5 V on B Port; (3)Control Inputs VIH/VIL Levels Are Referenced to VCCA Voltage; (4)Latch-Up Performance Exceeds 250 mA Per JESD 17; (5)ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A); 200-V Machine Model (A115-A). 1000-V Charged-Device Model (C101).
