Product Summary
The VPX3226E-A2 is a Video Pixel Decoder. The VPX3226E-A2 is the third generation of full feature video acquisition ICs for consumer video and multimedia applications. All of the processing necessary to convert an analog video signal into a digital component stream have been integrated onto a single 44-pin IC.
Parametrics
VPX3226E-A2 absolute maximum ratings: (1)TA Ambient Temperature: 0 to 65 °C; (2)TS Storage Temperature: –40 to 125 °C; (3)TJ Junction Temperature: 0 to 125 °C; (4)VSUPA Supply Voltage, all Supply Inputs: –0.3 to 6 V; (5)VSUPD: –0.3 to 4 V; (6)PTOT MAX Power Dissipation due to package characterstics (PMQFP44)VDD, PVDD, AVDD: 935 mW.
Features
VPX3226E-A2 features: (1)hue, brightness, contrast, and saturation control; (2)dual window cropping and scaling; (3)horizontal resizing between 32 and 864 pixels/line; (4)vertical resizing by line dropping; (5)high-quality anti-aliasing filter; (6)scaling controlled peaking and coring; (7)44-pin PLCC and PMQFP packages; (8)reduced power consumption of below 500 mW; (9)I2C serial control, 2 different device addresses; (10)on-chip clock generation, only one crystal needed for all standards; (11)user programmable output pins; (12)power-down mode; (13)IEEE 1149.1 (JTAG)boundary scan interface; (14)8 input or user programmable output pins.
