Product Summary

The SKKE310F12 is a Fast Diode Module. The applications of the SKKE310F12 include self-commutated inverters, DC choppers, AC motor speed control, Inductive heating, Uninterruptible power supplies, Electronic welders, General power switching applications.

Parametrics

SKKE310F12 absolute maximum ratings: (1)IFAV: 220A; (2)IFSM: 4000A; (3)I2T: 80000A2S; (4)VF: max.2,2V; (5)V(to): max.1,2V; (6)rT, Tvj=25℃: max.2,75V; (7)IRD, Tvj=150℃: max.80mA.

Features

SKKE310F12 features: (1)CAL (control axial lifetime) technology patent NO.DE 43 10 44; (2)Heat transfer through ceramic isolated metal baseplate; (3)Very short recovery times; (4) soft recovery; (5)Low switching losses.

Diagrams

SKKE310F12 pin connection
