Product Summary

The SKiiP14AC065V1 is a 3-phase bridge inverter. The applications of the SKiiP14AC065V1 include Inverter up to 10kVA, Typical motor power 5.5kW.

Parametrics

SKiiP14AC065V1 absolute maximum ratings: (1)VCES: 1200V; (2)IC: 28A; (3)ICRM: 30A; (4)VGES: ±20V; (5)TJ: -40 to 150℃; (6)ItRMS: 40A; (7)Tstg: -40 to 125℃; (8)Visol: 2500V.

Features

SKiiP14AC065V1 features: (1)ultrafast NPT IGBTS; (2)Robust and soft freewheeling diodes in CAL technology; (3)Highly reliable spring contacts for electrical connections; (4)UL recognised file no.E63532.

Diagrams

SKiiP14AC065V1 pin connection
